2026 MaxxD Trailers U5X8320

HEAVY DUTY UTILITY MUSCLE

The U5X Tandem Axle Utility Trailer is a 14,000 lbs GVWR utility trailer made for the working man. It’s an all-around versatile trailer for construction purposes and it can haul heavy materials and equipment like mini excavators or tractors with your ¾ ton truck. The U5X deck is 20’ long and 83 inches wide, and it weighs 3,500 lbs, so you can haul close to 10,500 lbs with this trailer.

Up front the U5X hooks to your vehicle with a 2 5/16” DEMCO EZ-Latch adjustable coupler, mounted to a 6” channel wrap tongue and a 5” x 3” x ¼” steel angle mainframe. The treated wood floor deck is supported by 3” channel crossmembers spaced at 16” apart, and a 10k drop leg jack raises and lowers the front of the trailer.

This trailer has a 16” tall 3” square tubing top-rail on the front and sides of the trailer, and has hooks and bullnose d-ring on the deck for easy tying down of cargo. Heavy-duty equipment standup ramps with built-in support knees make loading and unloading your equipment easy and safe.

Two 7,000 lb electric brake axles paired with 235/80 10-ply Radial tires carry the U5X down the road. Along with steel diamond plate fenders, this trailer has clear LED running lights on the sides and in the rear bumper as well.

Like all of our trailers, the U5X is 100% built in Texas, and is ready to get work done. We build trailers so you can dream big and work hard.

2026 MaxxD Trailers U5X8320

HEAVY DUTY UTILITY MUSCLE

The U5X Tandem Axle Utility Trailer is a 14,000 lbs GVWR utility trailer made for the working man. It’s an all-around versatile trailer for construction purposes and it can haul heavy materials and equipment like mini excavators or tractors with your ¾ ton truck. The U5X deck is 20’ long and 83 inches wide, and it weighs 3,500 lbs, so you can haul close to 10,500 lbs with this trailer.

Up front the U5X hooks to your vehicle with a 2 5/16” DEMCO EZ-Latch adjustable coupler, mounted to a 6” channel wrap tongue and a 5” x 3” x ¼” steel angle mainframe. The treated wood floor deck is supported by 3” channel crossmembers spaced at 16” apart, and a 10k drop leg jack raises and lowers the front of the trailer.

This trailer has a 16” tall 3” square tubing top-rail on the front and sides of the trailer, and has hooks and bullnose d-ring on the deck for easy tying down of cargo. Heavy-duty equipment standup ramps with built-in support knees make loading and unloading your equipment easy and safe.

Two 7,000 lb electric brake axles paired with 235/80 10-ply Radial tires carry the U5X down the road. Along with steel diamond plate fenders, this trailer has clear LED running lights on the sides and in the rear bumper as well.

Like all of our trailers, the U5X is 100% built in Texas, and is ready to get work done. We build trailers so you can dream big and work hard.

Features May Include:

• 2 5/16″ ADJUSTABLE COUPLER
• 1 – 10K DROP-LEG JACK
• 6″ CHANNEL WRAP TONGUE
• 3X5X1/4″ ANGLE FRAME
• 3″ CHANNEL ON 16″ CENTERS”
• 3″ SQ TUBE TOP RAILS 1′ DOVETAIL/EQUIPMENT STAND-UP RAMPS
• 2-7K ELECTRIC BRAKE AXLES
• SLIPPER SPRING SUSPENSION
• ST235/80R16 E RADIAL TIRES 7K
• DOUBLE BROKE DIAMOND PLATE FENDERS
• 2X8 TREATED WOOD FLOOR
• FLUSHMOUNT LED’S/STANDARD WIRING

Options:

TONGUE/NECKS:

• 6 in CHANNEL WRAP TONGUE

DOVETAILS:

• 1 ft DOVETAIL/4' SPRING GATE

SPARES:

• SPARE ST235/80R16 E RADIAL TIRE
